49242432000C Diebold Opteva 2.0 AFD Picker

49242432000C Diebold Opteva 2.0 AFD Picker - Precision Cash Handling Solution

49242432000C Diebold Opteva 2.0 AFD Picker is an Advanced Function Dispenser (AFD) 2.0 picker assembly designed for compatible Diebold Nixdorf ATM cash-dispensing systems. The picker is a core component of the AFD mechanism, responsible for selecting banknotes from the cash cassette and feeding them into the downstream dispensing path.Diebold Nixdorf's official CS5550 product card confirms the use of Advanced Function Dispenser (AFD 2.0), with up to four media cassettes and a bundle presenter capacity of up to 50 notes.

​​​​​​​

Key Features and Benefits

Precision Banknote Picking

The AFD 2.0 Picker is the picking stage of the cash-dispensing mechanism. Its primary function is to separate and pick banknotes from the cassette before the notes enter the transport and stacking stages. This makes the picker critical to stable cash-dispensing performance and transaction reliability.

AFD 2.0 Architecture

The part is identified in public parts references as PICKER, AFD 2.0, ASSEMBLY and is associated with the AFD 2.0 dispenser architecture used in Diebold Nixdorf 5500/5550-class systems.

Compatible with AFD 2.0 Cash Dispensing Systems

Diebold Nixdorf's official CS5550 product documentation specifies an AFD 2.0 dispensing system with up to four media cassettes, 340 mm stacking space per cassette, and a bundle presenter supporting up to 50 notes.

Replacement and Maintenance Application

49242432000C is suitable for ATM maintenance and replacement applications where the installed mechanism requires the corresponding AFD 2.0 picker assembly. The PN should be verified against the customer's existing assembly before ordering because AFD configurations and revisions can vary.

Technical Specifications

Trading Information

Why Choose Our Solution

Extensive ATM Parts Experience

We specialize in ATM spare parts and cash-handling mechanisms, covering major ATM brands and dispensing platforms, including Diebold Nixdorf AFD systems.

Comprehensive Compatibility Support

Before shipment, we can verify the customer's PN, existing picker assembly, dispenser model and mechanism configuration to reduce compatibility risks.

Quality Assurance

Each available 49242432000C replacement assembly can be checked for part-number identification, physical condition and functional compatibility before shipment.

The supplied product is covered by a 180-day warranty.

Flexible Support Options

We provide online technical assistance and video remote support for customers during installation, replacement and troubleshooting.

Installation and Maintenance

Easy Integration Process

49242432000C is designed as a replacement assembly for the corresponding AFD 2.0 Picker. During replacement, technicians should first confirm the existing part number and compare the mechanical configuration of the installed picker with the replacement assembly.

Maintenance Recommendations

Regular inspection of the picking mechanism, friction surfaces, shafts, bearings and related transport components can help maintain stable banknote feeding performance. Any worn or contaminated picking components should be inspected and replaced according to the service requirements of the specific dispenser.

Ongoing Technical Support

Technical assistance can be provided remotely for compatibility confirmation, installation guidance and troubleshooting. Customers are encouraged to provide the existing PN and mechanism photos before ordering.

Frequently Asked Questions

Q1: What is the 49242432000C / 49-242432-000C?

A: 49242432000C, also identified as 49-242432-000C, is a Diebold Nixdorf AFD 2.0 Picker Assembly used in compatible ATM cash-dispensing systems. Public parts references identify the PN as “PICKER, AFD 2.0, ASSEMBLY” and associate it with Opteva 5500/5550-class AFD applications.

Q2: What does an AFD Picker do?

A: The AFD Picker is the banknote-picking stage of an Advanced Function Dispenser. It selects banknotes from the media cassette and feeds them into the downstream dispensing mechanism, where the notes can subsequently be stacked, transported and presented to the customer.

Q3: Which ATM models use 49242432000C?

A: Public parts references associate 49-242432-000C with Diebold Opteva 5500/5550 and AFD 2.0 systems, while other industry listings associate it with DN100-related applications. Because configurations can vary by revision and dispenser assembly, the installed PN should be checked before ordering.

Q4: What is AFD 2.0?

A: AFD 2.0 stands for Advanced Function Dispenser 2.0. Diebold Nixdorf's official CS5550 product card lists AFD 2.0 as its media technology and specifies up to four media cassettes, 340 mm stacking space per cassette, and a bundle presenter supporting up to 50 notes.

Q5: How many cassettes does the related AFD 2.0 system support?

A: The official CS5550 product card specifies up to four media cassettes for its AFD 2.0 configuration. It also specifies 340 mm of stacking space per cassette. Actual cassette configuration can depend on the particular ATM installation.

Q6: What is the warranty period?

A: The warranty period for this supplied replacement part is 180 days. Warranty coverage is subject to the supplier's warranty terms. Customers should contact technical support promptly if a functional problem occurs during the warranty period.
