Hyosung CDU10 Upper Feed Module

Hyosung CDU10 Upper Feed Module - Premium ATM Cash Dispenser Component

The Hyosung CDU10 Upper Feed Module (Part Number: 7310000386) represents a critical cash dispensing component engineered for Hyosung Monimax SF12 and SF34 ATM systems. Backed by RM's 20 years of industry experience and ISO 9001:2008 certification, this module ensures reliable note feeding performance in high-volume banking environments. With over 5 years of specialized supply experience for this specific module, RM provides comprehensive sub-module support and individual spare parts across all CDU10 Upper Feed Module configurations. The system incorporates precision-engineered feed roller separators, solenoid-controlled separation mechanisms, and sensor-based timing wheels to deliver consistent banknote processing. Available in both brand new and refurbished conditions, each unit undergoes strict quality control across our 3,000-square-meter manufacturing facility.

​​​​​​​

Product Overview

The product serves as the primary banknote feeding mechanism in cash dispenser units. This module manages the critical initial stage of currency dispensing by separating, aligning, and feeding individual notes from the cassette into the transport path.

Each module features multiple configuration options to match specific ATM deployment requirements. The Type 1/2 and Type 3 feed roller separators accommodate different banknote specifications and operational environments.

The integrated V Sensor Module provides real-time feedback on note position and movement. This sensor technology ensures accurate timing coordination with downstream transport components. The timing wheel mechanism synchronizes all mechanical movements for smooth operation.

Technical Specifications

Component Configuration

Key Benefits

Your ATM operations demand zero-downtime reliability. The Hyosung CDU10 Upper Feed Module delivers precisely that through its robust mechanical design and high-quality component materials.

Complete Parts Coverage: We supply every individual component within the module assembly. Whether you need a complete module replacement or a single separator roll, RM maintains comprehensive inventory availability.

Proven Supply Record: Over 5 years of dedicated support for this specific module means we understand every common failure point. Our technical team can guide you through preventive maintenance schedules based on real-world deployment data.

Dual Condition Options: Choose between brand new modules for maximum longevity or refurbished units that deliver excellent performance at optimized cost points. All refurbished units undergo identical testing protocols as new inventory.

Fast Technical Response: Our 24-hour inquiry response guarantee ensures your questions never wait. Online technical support includes remote diagnostics, installation guidance, and troubleshooting assistance.

Flexible Logistics: We support sea freight, air freight, and international express delivery. Your location and urgency determine the most cost-effective shipping solution.

Application Scenarios

This upper feed module operates as the first mechanical interface with stored banknotes. When your ATM receives a withdrawal command, the CDU10 module separates individual notes from the stack and initiates the transport sequence.

The Type 1/2 configuration suits standard polymer and cotton-fiber currency in moderate humidity environments. Type 3 configurations handle worn or wrinkled notes more effectively through modified roller pressure profiles.

Financial institutions operating SF12 or SF34 Monimax systems across multiple branches benefit from standardized module specifications. Maintaining spare CDU10 modules reduces mean-time-to-repair when service interventions become necessary.

Currency processing centers performing ATM refurbishment can source individual wear components like separator rolls and solenoids. This component-level serviceability extends overall module lifespan and reduces total cost of ownership.

Quality Assurance

Every module ships after passing multi-point inspection protocols within our QC Department. Functional testing includes roller rotation resistance measurement, solenoid response timing verification, and sensor signal integrity checks.

Our ERP management system tracks each component batch through production, assembly, and final testing stages. This traceability ensures consistent quality across all shipments and enables rapid root-cause analysis if performance issues arise.

The 30-day warranty period covers manufacturing defects and performance deviations from specified parameters. Online support remains available throughout your module's operational life for technical consultation and maintenance guidance.

FAQ

Q: What's the difference between Type 1/2 and Type 3 feed roller separators?

A: Type 1/2 separators use standard roller durometer and pressure settings for new or well-maintained currency. Type 3 versions employ modified roller compounds and increased separation pressure to handle aged or damaged notes that may stick together. Your choice depends on cash condition and environmental factors like humidity levels.

Q: Can I order individual components instead of the complete module?

A: Absolutely. We maintain inventory for all sub-components listed in the configuration table. Many maintenance teams prefer stocking high-wear items like separator rolls and solenoids while keeping complete modules for emergency replacements. Contact Tang@atm-part.com with your specific part requirements.

Q: How do I determine if my module needs replacement or just component servicing?

A: Common symptoms include repeated double-feed errors, inconsistent note pickup, or mechanical noise during operation. If your V Sensor Module shows consistent readings but mechanical separation fails, roller or solenoid replacement often resolves the issue. Complete module replacement becomes necessary when the drive gear or timing wheel shows wear beyond specification. Our technical team can help diagnose your specific situation through remote support.

Q: What shipping method do you recommend for urgent replacements?

A: For time-critical situations, international express delivery typically achieves 3-5 day delivery to major cities worldwide. Air freight offers a cost-performance balance with 7-10 day delivery windows. We'll provide detailed shipping options with your quote based on your location and timeline requirements.

Contact Us

Ready to secure your Hyosung CDU10 module supply with Hyosung CDU10 Upper Feed Module? Reach out to Tang@atm-part.com today for quotations, technical specifications, or customized solutions.
